SUN HYDRAULICS
RQCBLQV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQCBLQV (RQCBLQV) is a kickdown relief cartridge designed to function similarly to a circuit breaker in an electrical system. This valve opens completely and remains open once the pressure at inlet port 1 surpasses the valve setting, allowing unrestricted flow from port 1 to tank port 2. The valve stays open as long as the pressure at port 1 exceeds that at port 2, requiring flow cessation and equal or greater pressure at port 2 for resetting. It features a main stage orifice protected by a 150-micron stainless steel screen, making it unsuitable for load-holding applications. It's intended for use on the actuator side of a system because flow must stop for the valve to reset; if used on the pump side, pump flow must be halted for resetting. Back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The relief cartridges are interchangeable with others of similar size due to their two-port design and Sun's floating style construction, which minimizes internal part binding risks from installation torque or machining variations. This model has a capacity of 12 gpm (45 L/min) and can operate up to a maximum pressure of 5000 psi (350 bar), with typical response times around 25 ms. Maximum leakage is specified as 2 in\u00b3/min (30 cc/min) at standard conditions. The adjustment mechanism allows five clockwise turns for increasing settings, with specific torque requirements provided for installation and adjustments. Weighing only .20 lb (.10 kg), this cartridge utilizes Viton seals, making it versatile and reliable for various hydraulic applications where quick pressure relief is crucial without holding loads.
