SUN HYDRAULICS
RQIBCAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQIBCAV (RQIBCAV) is a kickdown relief cartridge designed to function similarly to a circuit breaker in an electrical system. This valve kicks completely open and remains open once the pressure at inlet port 1 surpasses the set threshold, providing an unrestricted flow path from port 1 to tank port 2. The valve stays open as long as the pressure at port 1 exceeds that at port 2. To reset, the flow from port 1 to port 2 must stop, and the pressure at port 2 should be equal to or greater than that at port 1. All two-port relief cartridges, except pilot reliefs, are interchangeable in terms of flow path and cavity for a given frame size. This cartridge features a main stage orifice protected by a 150-micron stainless steel screen and is not suitable for load-holding applications. It is intended for use on the actuator side of hydraulic systems, as flow through the valve must cease for resetting; if used on the pump side, pump flow must be stopped for resetting. The back pressure on tank port 2 adds directly to the valve setting at a ratio of 1:1. The corrosion-resistant design incorporates Sun's floating style construction to minimize internal binding risks due to excessive installation torque or cavity/cartridge machining variations. It fits into Cavity T-16A with Series 3 capacity up to 100 gpm (380 L/min) and operates at a maximum pressure of 5000 psi (350 bar). Typical response time is around 25 ms with maximum leakage of approximately four cubic inches per minute at specified conditions. It requires specific installation torques and adjustments detailed in its technical specifications, making it versatile yet precise in hydraulic applications like portable grain augers for silos where safety mechanisms are crucial.
