SUN HYDRAULICS
RQIBCCN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQIBCCN (Material Number: RQIBCCN) is a kickdown relief cartridge designed to function similarly to a circuit breaker in hydraulic systems. When the pressure at inlet port 1 exceeds the valve setting, the valve opens completely, creating an unrestricted flow path from port 1 to tank port 2. It remains open as long as the pressure at port 1 is higher than at port 2. To reset, flow must stop, and pressure at port 2 must equal or exceed that at port 1. This cartridge is physically and functionally interchangeable with other two-port relief cartridges of the same frame size but is not suitable for load holding applications. It is intended for use on the actuator side of a system since flow must cease for resetting; if used on the pump side, pump flow must be shut off for resetting. The main stage orifice features a protective 150-micron stainless steel screen, and back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. Corrosion-resistant options are available with external stainless steel or zinc-nickel plated components. The cartridge incorporates Sun's floating style construction to minimize internal binding risks due to excessive torque or machining variations. The RQIBCCN model has a capacity of 100 gpm (380 L/min) with a maximum operating pressure of 5000 psi (350 bar) and typical response time of 25 ms. It features an adjustment range with five clockwise turns needed to increase settings and includes specific installation and torque specifications. The model weighs approximately 1.20 lb (0.55 kg) and uses Viton seal kits (990-016-006). This product is ideal for applications like portable grain augers where safety mechanisms are crucial, allowing quick release when necessary while preventing false trips through built-in overlap design.
