SUN HYDRAULICS
RQIBKQN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQIBKQN (Material Number: RQIBKQN) is a specialized kickdown relief cartridge designed to function similarly to a circuit breaker within hydraulic systems. This valve operates by completely opening and maintaining an open state once the pressure at inlet port 1 surpasses the valve's set threshold, thereby allowing unrestricted flow from port 1 to tank port 2. The valve remains open as long as the pressure at port 1 is greater than at port 2. To reset this valve, flow between these ports must cease, and pressure at port 2 should be equal to or greater than that at port 1. This model is not suitable for load holding applications and is intended for use on the actuator side of hydraulic systems, requiring cessation of flow for resetting. If applied on the pump side, pump flow must be stopped for reset functionality. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and reliability in operation. Additionally, back pressure on tank port 2 adds directly to the valve setting at a one-to-one ratio. The RQIBKQN utilizes Sun's floating style construction to minimize risks of internal component binding due to excessive installation torque or machining variations in cavity/cartridge designs. It features a cavity T-16A Series 3 with a capacity of up to 100 gpm (380 L/min) and can withstand maximum operating pressures of up to 5000 psi (350 bar). Response time is typically around 25 milliseconds with maximum leakage limited to four cubic inches per minute at specific conditions. For installation and adjustments, the valve requires specific torque settings: installation torque ranges from 150\u2013160 lbf ft (203\u2013217 Nm), while locknut torque ranges from 80\u201390 lbf in (9\u201310 Nm). The model weighs approximately 1.20 lb (0.55 kg) and includes an adjustment screw with an internal hex size of 5/32 inches (4 mm).
