SUN HYDRAULICS
RQKBKAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQKBKAN (Material Number: RQKBKAN) is a specialized kickdown relief cartridge designed to function similarly to a circuit breaker in hydraulic systems. When the inlet port 1 pressure surpasses the valve setting, this valve fully opens, allowing an unrestricted flow path from port 1 to tank port 2. The valve remains open as long as the pressure at port 1 exceeds that at port 2. To reset, the flow must stop, and the pressure at port 2 must be equal to or greater than that at port 1. This cartridge is interchangeable with other two-port relief cartridges of the same frame size and features a main stage orifice protected by a 150-micron stainless steel screen. It is not suitable for load holding applications and should be used on the actuator side of systems since flow cessation is required for resetting. If used on the pump side, pump flow must be halted for reset. The RQKBKAN model supports a maximum operating pressure of 5000 psi (350 bar) and has a typical response time of 25 ms. It can manage up to 200 gpm (760 L/min) capacity with minimal leakage under specified conditions. The valve's design incorporates Sun's floating style construction to minimize issues from installation torque or machining variations. Back pressure on tank port 2 directly affects valve settings at a ratio of 1:1, making it crucial in system design considerations. This model weighs approximately 2.50 lb (1.15 kg) and includes options for corrosion-resistant materials identified by specific suffixes in their model codes for use in harsh environments. The adjustment mechanism allows fine-tuning with up to five clockwise turns to increase settings, ensuring precise control in various applications such as agricultural equipment safety mechanisms like portable grain augers.
