SUN HYDRAULICS
RQKBKEN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQKBKEN (RQKBKEN) is a specialized kickdown relief cartridge designed to function similarly to a circuit breaker in hydraulic systems. This valve kicks completely open when the inlet pressure at port 1 exceeds its preset threshold, allowing an unrestricted flow path to tank port 2. It remains open as long as the pressure at port 1 surpasses that at port 2, and it resets only when flow ceases and the pressures equalize. Notably interchangeable with other 2-port relief cartridges of similar frame sizes, this valve is equipped with a protected main stage orifice via a 150-micron stainless steel screen. However, it is not recommended for load-holding applications due to its reset mechanism requirements. The RQKBKEN is intended primarily for use on the actuator side of hydraulic systems; if applied on the pump side, pump flow must be halted for resetting. Back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The model incorporates corrosion-resistant features with options for external stainless steel or zinc-nickel plating components identified by specific suffixes in the model code. Constructed with Sun's floating style design, it minimizes internal binding risks from excessive installation torque or machining variations. The valve can handle capacities up to 200 gpm (760 L/min) and operates under pressures up to 5000 psi (350 bar), with typical response times around 25 ms. It features adjustable settings via a screw mechanism and includes specific installation torque requirements. This versatile component finds applications where quick pressure relief is critical, such as in agricultural equipment like portable grain augers, offering safety measures by tripping under excessive loads to prevent equipment damage or personal injury.
