SUN HYDRAULICS
RQKBKEV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RQKBKEV (RQKBKEV) is a specialized kickdown relief cartridge designed to function similarly to a circuit breaker in hydraulic systems. This valve automatically opens completely and remains open once the pressure at inlet port 1 surpasses the set threshold, facilitating an unrestricted flow path to tank port 2. The valve will stay open as long as the pressure at port 1 is greater than at port 2. To reset the valve, flow must stop, and pressure at port 2 must equal or exceed that at port 1. The RQKBKEV is physically and functionally interchangeable with other two-port relief cartridges of the same frame size, excluding pilot reliefs. It features a main stage orifice protected by a 150-micron stainless steel screen, making it unsuitable for load-holding applications. This cartridge is intended for use on the actuator side of systems; if used on the pump side, pump flow must be halted for resetting. Back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The RQKBKEV incorporates corrosion-resistant design options identified by model code suffixes AP or LH for external stainless steel or zinc-nickel plated components, respectively. Its floating style construction minimizes internal binding risks due to excessive installation torque or machining variations. With a capacity of up to 200 gpm (760 L/min) and a maximum operating pressure of 5000 psi (350 bar), this cartridge provides reliable performance with typical response times around 25 ms and minimal leakage rates under specified conditions. Adjustments can be made via an internal hex screw with specific torque requirements for installation and locknut settings. Notably used in applications like portable grain augers for silos, this kickdown relief helps prevent equipment damage by providing an escape route when unexpected blockages occur.
