SUN HYDRAULICS
RSBCLCN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RSBCLCN (RSBCLCN) is a pilot-operated, balanced piston sequence valve designed to supply a secondary circuit with flow once the inlet port pressure exceeds the valve setting. This versatile valve manages pressure at port 1 relative to port 3, remaining unaffected by back pressure at port 2 up to its setting. It can substitute for 2-port relief valves when there's return line pressure and features interchangeable design across all 3-port sequence cartridges with the same flow path and cavity size. The valve's main stage orifice is protected by a durable 150-micron stainless steel screen, and it offers a minimum setting of 75 psi (5 bar). Pressure at port 3 adds directly to the valve setting at a 1:1 ratio, with a maximum allowable pressure of 5000 psi (350 bar). Not suitable for load-holding applications due to potential spool leakage, this model is compatible with phosphate ester fluids when configured with EPDM seals but should avoid petroleum-based substances. The floating style construction minimizes internal part binding risks from excessive torque or machining variations. With a capacity of 7.5 gpm (30 L/min) and factory settings established at 4 gpm (15 L/min), it operates under pressures up to 5000 psi (350 bar) and responds typically within 10 ms. Valve leakage at standard conditions is minimal, recorded at up to 2 in/min (30 cc/min). Adjustment requires five clockwise turns for increased settings, using an internal hex screw size of 5/32 in (4 mm), while installation torque ranges from 20\u201325 lbf ft (27\u201333 Nm). The model weighs approximately .30 lb (.15 kg) and utilizes Viton seal kits for maintenance.
