SUN HYDRAULICS
RSDSCBN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RSDSCBN (RSDSCBN) is a pilot-operated, balanced poppet sequence valve designed to manage secondary circuit flow once the inlet port 1 pressure surpasses the valve setting. This valve precisely controls pressure at port 1 in relation to the drain port 3, remaining unaffected by back pressure at port 2 up to its set point. It can substitute for two-port relief valves when there is return line pressure, and all three-port sequence cartridges are interchangeable in terms of flow path and cavity size. The RSDSCBN features a 150-micron stainless steel screen protecting the main stage orifice and can handle up to 5000 psi (350 bar) at port 3. It's suitable for load-holding applications and is resistant to cavitation-related issues such as noise and manifold erosion due to internal modulating. This valve can accept maximum pressure at port 2, making it ideal for cross-port relief circuits. Its floating style construction minimizes binding risks from excessive torque or machining variations. With a capacity of 15 gpm (60 L/min), maximum operating pressure of 5000 psi (350 bar), and a typical response time of 10 ms, this valve ensures efficient performance. It has minimal leakage at reseat with only 10 drops/min (0.7 cc/min). The adjustment requires five clockwise turns to increase settings, with installation torque between 30-35 lbf-ft (41-47 Nm). The model weighs .30 lb (.15 kg) and uses a Viton seal kit with part number 990011006 for maintenance needs.
