SUN HYDRAULICS
VALVE
RSDSLAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RSDSLAN (RSDSLAN) is a pilot-operated, balanced poppet sequence valve designed to supply a secondary circuit with flow once the pressure at inlet port 1 exceeds the valve setting. It effectively controls the pressure at port 1 relative to the drain port 3, remaining unaffected by back pressure at port 2 up to the valve setting. This makes it suitable for use in place of two-port relief valves when there is pressure in the return line. The RSDSLAN model features a robust design that allows all three-port sequence cartridges to be physically and functionally interchangeable, providing flexibility in various applications. It incorporates a main stage orifice protected by a 150-micron stainless steel screen and can handle pressures at port 3 directly additive to the valve setting up to a maximum of 5000 psi (350 bar). Ideal for load-holding applications, this valve is immune to cavitation-related issues such as noise and manifold erosion due to its internal modulating mechanism. It also supports maximum pressure at port 2, making it suitable for cross-port relief circuits. The Sun floating style construction minimizes internal part binding risks due to excessive torque or machining variations. With a capacity of 15 gpm (60 L/min) and factory pressure settings established at 4 gpm (15 L/min), it offers quick response times typically around 10 ms and minimal leakage rates upon reseat. The valve's installation requires specific torque settings, including a valve hex size of .78 in (22.2 mm) and locknut hex size of .916 in (15 mm). The model weighs approximately .30 lb (.15 kg) and uses Viton seals for optimal performance under various conditions.
