SUN HYDRAULICS
RSHCQAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RSHCQAV (RSHCQAV) is a pilot-operated, balanced piston sequence valve designed to supply a secondary circuit with flow once the inlet port 1 pressure exceeds the valve setting. This valve is ideal for applications where pressure regulation is required in place of 2-port relief valves, especially when there is pressure in the return line. It features a 150-micron stainless steel screen protecting the main stage orifice and is insensitive to back pressure at port 2 sequence up to the valve setting. The valve's construction allows for interchangeable use across all 3-port sequence cartridges, maintaining consistent flow paths and cavity sizes for a given frame size. The RSHCQAV model incorporates Sun's floating style construction to reduce internal binding risks due to excessive installation torque or machining variations. It has a maximum operating pressure of 5000 psi (350 bar) and a capacity of 60 gpm (240 L/min). The control pilot flow ranges from 15 to 20 in\u00b3/min (0.25 to 0.33 L/min), with typical response times around 10 ms. Valve leakage at maximum conditions measures approximately 4 in\u00b3/min (65 cc/min) at 1000 psi (70 bar). Adjustments can be made using W or Y controls, with or without special settings, and are adjustable throughout their full range when no special setting is specified. The valve's hex size is 1-1/4 inches (31.8 mm), with an installation torque requirement of 150-160 lbf-ft (203-217 Nm). It weighs approximately 1.50 lb (0.70 kg) and uses Viton seal kits for optimal performance under various conditions.
