SUN HYDRAULICS
RSHSLWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RSHSLWV (RSHSLWV) is a pilot-operated, balanced poppet sequence valve designed to supply a secondary circuit with flow once the inlet port pressure exceeds the valve setting. This versatile valve controls the pressure at port 1 relative to the drain port 3 and is insensitive to back pressure at port 2 up to the valve setting. It can be used to regulate pressure in place of two-port relief valves when there is pressure in the return line. All three-port sequence cartridges from Sun Hydraulics are interchangeable, offering consistent flow paths and cavity compatibility for a given frame size. The main stage orifice in this model is protected by a 150-micron stainless steel screen, ensuring durability and reliability. The RSHSLWV is suitable for load-holding applications and features modulating that occurs inside the cartridge, making it resistant to issues like cavitation noise and manifold erosion. This valve can handle maximum pressure at port 2 and is ideal for cross-port relief circuits. Its construction minimizes internal part binding due to excessive installation torque or machining variations. Key specifications include a T-17A cavity, Series 3 capacity of 60 gpm (240 L/min), maximum operating pressure of 5000 psi (350 bar), typical response time of 10 ms, and maximum valve leakage at reseat of 10 drops/min (0.7 cc/min). The adjustment allows for five clockwise turns to increase settings, with a valve hex size of 1-1/4 inches (31.8 mm) and an installation torque range of 150-160 lbf ft (203-217 Nm). The model weighs approximately 1.50 lb (0.70 kg) and includes a Viton seal kit for reliable performance in demanding conditions.
