SUN HYDRAULICS
RSJCLAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RSJCLAV (RSJCLAV) is a pilot-operated, balanced piston sequence valve designed to supply a secondary circuit with flow once the inlet port pressure exceeds the valve setting. This model controls the pressure at port 1 relative to the drain port 3 and is insensitive to back pressure at port 2 up to the valve setting, making it suitable for use as a pressure regulator in place of two-port relief valves when there is return line pressure. The RSJCLAV features interchangeable three-port sequence cartridges with consistent flow paths and cavity compatibility for a given frame size. It includes a 150-micron stainless steel screen protecting the main stage orifice and incorporates Sun's floating style construction to reduce internal binding risks due to installation torque or machining variations. The valve operates with a maximum operating pressure of 5000 psi (350 bar) and has a factory pressure setting established at 4 gpm (15 L/min). Its control pilot flow ranges between 15-20 in\u00b3/min (0.25-0.33 L/min), with typical response times around 10 ms. The design allows for adjustment throughout its full range using W or Y controls unless specified otherwise for special settings, which denote maximum valve settings. This model is not suitable for load holding applications due to spool leakage and features an adjustment screw internal hex size of 5/32 in (4 mm) with locknut torque specifications of 80-90 lbf-in (9-10 Nm). Weighing approximately 3.10 lb (1.40 kg), it requires an installation torque between 350-375 lbf-ft (474-508 Nm).
