SUN HYDRAULICS
RVBBLBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVBBLBV (RVBBLBV) is a three-port normally closed modulating element with relief, designed to perform dual functions when used with an external orifice. This component acts as a bypass compensator, managing priority flow into a circuit as dictated by the external orifice, while excess input flow is redirected to tank port 2. Additionally, if pressure at inlet port 1 exceeds the valve setting, it functions as a standard relief valve. It offers compensating pressure across all ranges at 50 psi (3.5 bar). The performance curve illustrates system pressure on the X-axis and the pressure differential across the control orifice on the Y-axis, with various curves representing different bypass flows. Importantly, this valve's capacity and performance are influenced by bypass flow rather than control flow. The RVBBLBV operates within a T-163A cavity and provides a series 0 capacity of up to 5 gpm (20 L/min), with factory pressure settings established at 4 gpm (15 L/min). It has a maximum operating pressure of 5000 psi (350 bar) and typical response time of 10 milliseconds. Maximum valve leakage at 110 SUS (24 cSt) is rated at 2 in\u00b3/min at 1000 psi (30 cc/min at 70 bar). To adjust settings, users can make up to five clockwise turns. The valve features a hex size of .34 inches (19.1 mm) for installation torque between 20-25 lbf ft (27-33 Nm), an internal hex size for adjustment screw of .532 inches (4 mm), and locknut hex size of .916 inches (15 mm), requiring locknut torque between 80-90 lbf in (9-10 Nm). The model weighs approximately .30 lb (.15 kg) and utilizes Viton seal kits.
