SUN HYDRAULICS
RVBBLNV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVBBLNV (Material Number: RVBBLNV) is a three-port normally closed modulating element with relief, designed to provide dual functions when used in conjunction with an external orifice. This component acts as a bypass compensator, controlling priority flow into a circuit as determined by the external orifice. Any input flow exceeding the priority flow is rerouted to tank port 2. Additionally, if the pressure at inlet port 1 surpasses the valve setting, it functions as a standard relief valve. It features a compensating pressure for all ranges set at 50 psi (3.5 bar). The performance curve of this valve illustrates that its capacity and performance are dictated by the bypass flow, independent of control flow. This model is housed in a T-163A cavity and offers a series 0 capacity of 5 gpm (20 L/min), with factory pressure settings established at 4 gpm (15 L/min). It boasts a maximum operating pressure of 5000 psi (350 bar) and typical response time of 10 milliseconds. The maximum valve leakage at 110 SUS (24 cSt) is limited to 2 in\u00b3/min (30 cc/min) under conditions up to 1000 psi (70 bar). The adjustment mechanism allows for up to five clockwise turns to increase settings, with specific hex sizes for both the valve and adjustment screw to facilitate installation and adjustments. The model weighs approximately .30 lb (.15 kg), and it uses Viton seal kits compatible with its cartridge design for reliable sealing performance.
