SUN HYDRAULICS
RVCALYN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVCALYN (Material Number: RVCALYN) is a ventable, pilot-operated, balanced piston relief cartridge designed for precise pressure regulation in hydraulic systems. These normally closed valves begin to open to tank port 2 when the inlet pressure at port 1 reaches the preset level, effectively throttling flow to maintain the desired pressure. The valve features a vent port (port 3) that allows for remote control via other pilot or two-way valves. Known for their accuracy and low-pressure rise versus flow characteristics, these valves operate smoothly and quietly with moderate speed. The RVCALYN model is capable of handling maximum pressure at port 2 and is suitable for cross-port relief circuits, though spool leakage should be considered in such applications. This valve's main stage orifice is protected by a 150-micron stainless steel screen, ensuring durability and reliability. However, it is not recommended for load-holding applications due to potential spool leakage. Back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. For systems utilizing phosphate ester fluids, cartridges with EPDM seals are available; however, these seals are incompatible with petroleum-based fluids. The RVCALYN incorporates Sun's floating style construction to minimize internal part binding due to excessive installation torque or machining variations. It fits into Cavity T-11A Series 1 and has a capacity of up to 15 gpm (60 L/min). The factory pressure settings are established at 4 gpm (15 L/min), with a maximum operating pressure of 5000 psi (350 bar). The control pilot flow ranges from 7-10 in\u00b3/min (0.11-0.16 L/min), with a typical response time of approximately 10 ms. Maximum valve leakage at standard viscosity measures up to 2 in\u00b3/min (30 cc/min) at 1000 psi (70 bar).
