SUN HYDRAULICS
RVCBKDV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVCBKDV (RVCBKDV) is a versatile hydraulic valve designed to perform dual functions when used in conjunction with an external orifice. It primarily acts as a bypass compensator, regulating priority flow into the circuit while redirecting any excess input flow to tank port 2. Additionally, if the pressure at inlet port 1 exceeds the valve's set threshold, it functions as a conventional relief valve. The compensating pressure varies across different ranges: 45 psi for A range, 30 psi for B range, and 100 psi for C range. The performance curve of this valve is characterized by system pressure on the X-axis and the pressure differential it creates across the control orifice on the Y-axis. This particular model is suitable for applications requiring precise control over bypass flows, with its capacity determined by bypass rather than control flow. The RVCBKDV features a cavity T-11A series 1 with a capacity of up to 10 gpm (40 L/min) and can operate at a maximum pressure of 5000 psi (350 bar). Its response time is typically around 10 ms, and it has minimal valve leakage under specified conditions. The valve's adjustment can be modified via clockwise turns to increase its setting, and it includes specific torque requirements for installation and adjustment. Weighing approximately .40 lb (0.20 kg), this model offers reliable performance in demanding hydraulic systems and comes with a Viton seal kit option for enhanced durability.
