SUN HYDRAULICS
RVCSCQV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVCSCQV (RVCSCQV) is a ventable, pilot-operated, balanced-poppet relief cartridge designed for precise pressure regulation in hydraulic systems. This valve is normally closed and begins to open to tank port 2 when the inlet port 1 pressure reaches the set level, effectively throttling flow to maintain desired pressure levels. It features a vent port (port 3) that enables remote control via other pilot or two-way valves, providing versatility in various control applications. The valve is engineered for smooth and quiet operation with moderate speed and low pressure rise versus flow characteristics. A significant advantage of the RVCSCQV is its immunity to cavitation-related issues such as noise and manifold erosion due to its internal modulation. It accommodates EPDM seals for compatibility with systems using phosphate ester fluids; however, exposure to petroleum-based substances can damage these seals. The cartridge can handle maximum pressures at port 2, making it suitable for cross-port relief circuits. A remote pilot relief on the vent port allows control below the valve's own setting. The design ensures reliability even with varying oil temperatures and contamination levels, thanks in part to a main stage orifice protected by a 150-micron stainless steel screen. Ideal for load-holding applications, any back pressure on tank port 2 directly adds to the valve setting at a 1:1 ratio. The Sun floating style construction minimizes binding risks from excessive torque or machining variations. This model fits cavity T-11A series 1 with a capacity of up to 15 gpm (60 L/min) and operates at pressures up to 5000 psi (350 bar). It features an adjustment screw with an internal hex size of 5/32 inch (4 mm), requiring specific torque settings for installation and locknut adjustments.
