SUN HYDRAULICS
RVEAKAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVEAKAN (RVEAKAN) is a ventable, pilot-operated, balanced piston relief cartridge designed as a pressure regulating valve. This device remains normally closed until the pressure at inlet port 1 reaches the predetermined valve setting. Once this threshold is reached, it begins to open towards tank port 2, effectively throttling flow to maintain regulated pressure levels. It features a vent port 3 that facilitates remote control through other pilot or two-way valves. Known for its accuracy and low pressure rise versus flow characteristics, the RVEAKAN operates smoothly and quietly while offering moderate speed in response time. It can accept maximum pressure at port 2, making it suitable for cross-port relief circuits; however, spool leakage should be considered in such applications. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and reliability. However, it is not advisable for load-holding applications due to potential spool leakage. The backpressure on tank port 2 directly adds to the valve setting at a 1:1 ratio, affecting its overall performance. Cartridges configured with EPDM seals are intended for systems using phosphate ester fluids; exposure to petroleum-based fluids may damage these seals. The RVEAKAN incorporates Sun's floating style construction to reduce internal part binding risks due to excessive installation torque or cavity/cartridge machining variations. With a capacity of up to 30 gpm (120 L/min) and a maximum operating pressure of 5000 psi (350 bar), it offers robust performance in various settings. The factory pressure settings are established at 4 gpm (15 L/min), with typical response times around 10 ms and maximum valve leakage at approximately 3 in\u00b3/min under specific conditions.
