SUN HYDRAULICS
RVEBLAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVEBLAN (RVEBLAN) is a versatile three-port, normally closed modulating element with relief functionality. It is designed to perform dual functions when combined with an external orifice. Primarily, it acts as a bypass compensator that regulates priority flow into a circuit as determined by the external orifice, while any surplus input flow is redirected to the tank port 2. Additionally, if the pressure at inlet port 1 surpasses the valve setting, it functions as a conventional relief valve. The compensating pressure across all ranges stands at 120 psi (8 bar). The performance curve illustrates the system pressure on the X-axis and the pressure differential induced by the valve across the control orifice on the Y-axis, with various curves depicting bypass flows. This model has a cavity T-2A series and boasts a capacity of up to 20 gpm (80 L/min), with factory pressure settings established at 4 gpm (15 L/min). It supports a maximum operating pressure of 5000 psi (350 bar) and typically responds within 10 ms. Maximum valve leakage at 110 SUS (24 cSt) is rated at 3 in\u00b3/min (50 cc/min) under conditions of 1000 psi (70 bar). Adjustment can be made by turning clockwise up to five turns to increase settings, facilitated by an internal hex screw size of 5/32 inch (4 mm). The locknut hex size is set at 9/16 inch (15 mm), requiring torque between 80-90 lbf-in (9-10 Nm). The model weighs .70 lb (.30 kg) and uses Viton seal kits for cartridge applications.
