SUN HYDRAULICS
RVEBLWN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVEBLWN (RVEBLWN) is a three-port normally closed modulating element with integrated relief functionality, designed to provide dual operations when paired with an external orifice. This component primarily functions as a bypass compensator, managing priority flow into a circuit as defined by the external orifice. Any input flow surpassing the designated priority flow is redirected to the tank port 2. Additionally, if pressure at inlet port 1 elevates to the valve's preset level, it transitions to operate as a standard relief valve. The compensating pressure across all ranges is set at 120 psi (8 bar), ensuring efficient system management. Performance curves illustrate system pressure on the X-axis against pressure differential on the Y-axis, highlighting various bypass flows which dictate valve capacity and performance\u2014independent of control flow considerations. The RVEBLWN features W and Y controls that can be specified with or without special settings; absent any special settings, these controls allow full-range adjustability. With special settings, they denote the valve's maximum setting capacity. The component boasts a cavity T-2A series 2 design with a capacity of 20 gpm (80 L/min) and can endure a maximum operating pressure of 5000 psi (350 bar). Its typical response time is approximately 10 ms, and it maintains minimal leakage under specified conditions. Installation specifications include a valve hex size of 1-1/8 inches (28.6 mm) and installation torque ranging from 45 to 50 lbf-ft (61 to 68 Nm). The adjustment screw has an internal hex size of 5/32 inches (4 mm), while the locknut requires torque between 80 to 90 lbf-in (9 to 10 Nm). Weighing in at .70 lb (.30 kg), this model includes a Viton seal kit for optimal performance in diverse applications.
