SUN HYDRAULICS
RVEBUWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVEBUWV (Material Number: RVEBUWV) is a three-port, normally closed modulating element designed to serve dual functions when used with an external orifice. Primarily, it acts as a bypass compensator, regulating priority flow into a circuit based on the external orifice while redirecting any excess flow from the input to the tank port 2. Additionally, if the pressure at inlet port 1 surpasses a certain threshold, it functions as a conventional relief valve. This product features a compensating pressure of 120 psi (8 bar) across all ranges and offers adjustable settings through W and Y controls, which can be customized with or without special settings. The valve's performance is depicted in its performance curve, where system pressure is plotted against the pressure differential created across the control orifice. The RVEBUWV operates within a cavity T-2A series 2 and has a capacity of 20 gpm (80 L/min). It can handle a maximum operating pressure of up to 5000 psi (350 bar) with an impressive response time of approximately 10 ms. The maximum valve leakage at 110 SUS (24 cSt) is rated at 3 in\u00b3/min (50 cc/min). Adjustments can be made by turning clockwise up to five full rotations to increase settings, with specific dimensions provided for installation and adjustment tools. Weighing just .70 lb (.30 kg), this model includes Viton seal kits for durability and reliability in various applications.
