SUN HYDRAULICS
RVEDCAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVEDCAN (Material Number: RVEDCAN) is a ventable, pilot-operated, balanced piston relief cartridge with an external drain, designed as a normally closed pressure regulating valve. This valve opens to the tank port when the inlet port pressure reaches the set threshold, effectively throttling flow to maintain desired pressure levels. It features a vent port for remote control and a drain port that ensures insensitivity to back pressure. The RVEDCAN is characterized by its precision, low-pressure rise versus flow, smooth operation, moderate speed, and quiet performance. It can handle maximum pressure at port 2 and is suitable for use in cross-port relief circuits; however, spool leakage should be considered in such applications. The main stage orifice is safeguarded by a 150-micron stainless steel screen. It's important to note that this valve isn't suitable for load-holding applications due to potential spool leakage. The valve's design incorporates Sun's floating style construction to mitigate risks of internal parts binding from excessive installation torque or machining variations. With a capacity of 30 gpm (120 L/min), it operates at a maximum pressure of 5000 psi (350 bar). The control pilot flow ranges between 10-15 in\u00b3/min (0.16-0.25 L/min), with typical response times around 10 ms. The adjustment requires up to five clockwise turns for increasing settings and features specific hex sizes for installation and adjustments. The valve weighs approximately 0.70 lb (0.30 kg) and uses Viton seal kits for cartridge sealing needs; however, EPDM seals are available for systems using phosphate ester fluids but should not be exposed to petroleum-based substances as they may cause damage.
