SUN HYDRAULICS
RVGAMYV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVGAMYV (RVGAMYV) is a ventable, pilot-operated, balanced piston relief cartridge designed to function as a pressure regulating valve. It remains normally closed until the inlet port reaches the preset pressure, at which point it begins to open to the tank port, throttling flow to regulate pressure. This model features a vent port for remote control by other pilot or 2-way valves, providing enhanced accuracy and smooth operation with low pressure rise versus flow. The cartridge is suitable for cross-port relief circuits and can handle maximum pressure at port 2; however, it should not be used in load-holding applications due to spool leakage. The valve incorporates Sun's floating style construction to minimize internal part binding due to excessive installation torque or machining variations. It is protected by a 150-micron stainless steel screen at the main stage orifice and features EPDM seals for use with phosphate ester fluids, though exposure to petroleum-based fluids can cause seal damage. The RVGAMYV has a capacity of 60 gpm (240 L/min) and operates at a maximum pressure of 5000 psi (350 bar). Its control pilot flow ranges from 15-20 in\u00b3/min (0.25-0.33 L/min), with a typical response time of 10 ms. Valve leakage at 110 SUS (24 cSt) is limited to 4 in\u00b3/min (65 cc/min) at 1000 psi (70 bar). The adjustment requires approximately five clockwise turns to increase setting, with specific torque values provided for installation and locknut adjustments. The valve weighs approximately 1.60 lb (0.70 kg) and includes options for Viton seal kits under part number 990017006.
