SUN HYDRAULICS
RVGBCBV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVGBCBV (RVGBCBV) is a three-port normally closed modulating element with relief capabilities, designed to provide dual functions when used with an external orifice. This component acts as a bypass compensator, regulating priority flow into a circuit based on the external orifice's specifications while directing excess flow to the tank port 2. Additionally, it functions as a standard relief valve if the pressure at inlet port 1 surpasses the valve's predetermined setting. The compensating pressure for all ranges is set at 120 psi (8 bar). Performance curves of this valve illustrate system pressure against the pressure differential created across the control orifice, with capacity and performance being dictated by bypass flow rather than control flow. The RVGBCBV fits into cavity T-17A and belongs to series 3, offering a capacity of up to 40 gpm (160 L/min). It can endure a maximum operating pressure of 5000 psi (350 bar) and typically responds within 10 milliseconds. Valve leakage is minimal, rated at a maximum of 4 in\u00b3/min (65 cc/min) at 110 SUS (24 cSt). Adjustment settings allow for up to five clockwise turns to increase the setting, with specific torque requirements for installation and adjustment components. The model weighs approximately 1.60 lb (0.70 kg) and utilizes Viton seals in its cartridge design.
