SUN HYDRAULICS
RVGBCCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVGBCCV (RVGBCCV) is a versatile three-port normally closed modulating element with relief, designed to offer dual functionality when paired with an external orifice. It primarily functions as a bypass compensator, regulating priority flow into a circuit based on the external orifice's specifications. Any incoming flow surpassing this priority flow is redirected to tank port 2. Additionally, if the pressure at inlet port 1 exceeds the valve setting, it operates as a traditional relief valve. This valve can accommodate a maximum operating pressure of 5000 psi (350 bar) and has a capacity of up to 40 gpm (160 L/min). With a compensating pressure of 120 psi (8 bar) across all ranges, its performance is depicted by curves that relate system pressure to the pressure differential created across the control orifice. The RVGBCCV\u2019s response time is typically around 10 ms and it exhibits minimal leakage at specified conditions. Installation requires specific torque settings for both the valve and locknut, ensuring secure operation. The adjustment mechanism allows for fine-tuning through clockwise turns to increase settings, supported by detailed hex size specifications for ease of maintenance and setup. This model weighs in at 1.60 lb (0.70 kg) and features Viton seal kits for reliable sealing performance under various conditions.
