SUN HYDRAULICS
RVGBKDV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVGBKDV (RVGBKDV) is a versatile three-port normally closed modulating element with relief, designed to offer dual functionality when paired with an external orifice. This component acts as a bypass compensator, efficiently controlling priority flow into a circuit as specified by the external orifice, while any excess input flow is diverted to tank port 2. In scenarios where the pressure at inlet port 1 escalates to the valve's preset level, it functions as a conventional relief valve. The compensating pressure across all ranges is set at 120 psi (8 bar). The performance curve illustrates system pressure on the X-axis and the pressure differential created by the valve across the control orifice on the Y-axis. These curves highlight various bypass flows, where capacity and performance are determined by bypass flow rather than control flow. The RVGBKDV model features a T-17A cavity type and Series 3 capacity, supporting up to 40 gpm (160 L/min). It can withstand a maximum operating pressure of 5000 psi (350 bar) and exhibits a typical response time of 10 ms. Maximum valve leakage at 110 SUS (24 cSt) is limited to 4 in\u00b3/min (65 cc/min). Users can adjust settings with up to 5.5 clockwise turns, utilizing an internal hex size of 5/32 inches (4 mm) for adjustments and a locknut hex size of 9/16 inches (15 mm). Installation requires torque between 150-160 lbf ft (203-217 Nm), while locknut torque should be maintained between 80-90 lbf in. (9-10 Nm). The model weighs approximately 1.60 lb (0.70 kg) and employs Viton seal kits for effective sealing solutions.
