SUN HYDRAULICS
RVGSCBN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVGSCBN (RVGSCBN) is a ventable, pilot-operated, balanced poppet relief cartridge designed for precise pressure regulation in hydraulic systems. These normally closed valves open to the tank port when the inlet pressure reaches the set value, effectively throttling flow to maintain consistent pressure levels. Featuring a vent port for remote control via external pilot or two-way valves, these cartridges offer high accuracy with minimal pressure rise relative to flow. They are engineered for smooth and quiet operation while providing moderate response speed. The internal modulating mechanism of the valve makes it resistant to cavitation-related issues such as noise and manifold erosion. These cartridges are ideal for load-holding applications, provided that any connected valving on the vent port is zero leak. They can handle maximum pressure at port 2 and are suitable for cross-port relief circuits. The valve setting can be controlled remotely via a pilot relief on the vent port. Additionally, they exhibit low sensitivity to oil temperature variations and contamination in hydraulic fluids. A 150-micron stainless steel screen protects the main stage orifice against debris. The RVGSCBN model incorporates Sun's floating style construction, which minimizes internal part binding due to installation torque or machining variations in cavities and cartridges. This model has a capacity of 50 gpm (200 L/min) and operates under pressures up to 5000 psi (350 bar). It features an adjustment range of up to 5 turns clockwise to increase settings, with specific torque requirements for installation and adjustments. The valve's robust design ensures reliability across various applications while maintaining low leakage rates at reseat conditions.
