SUN HYDRAULICS
RVISKAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics RVISKAN (Material Number: RVISKAN) is a ventable, pilot-operated, balanced poppet relief cartridge designed for precise pressure regulation. This valve remains normally closed and begins to open at the inlet port 1 once the preset pressure is reached, directing flow to tank port 2 to maintain a stable system pressure. It features a vent port 3 that allows for remote control via other pilot or two-way valves, making it suitable for load-holding applications provided any valving on the vent port is zero leak. The RVISKAN model can handle maximum pressure at port 2 and is effective in cross-port relief circuits. It includes a remote pilot relief option on the vent port to control the valve below its own setting. This valve operates effectively despite varying oil temperatures and contamination, thanks to its robust design featuring a main stage orifice protected by a 150-micron stainless steel screen. Additionally, back pressure on the tank port directly adds to the valve setting at a 1:1 ratio. The RVISKAN incorporates Sun's floating style construction to prevent internal binding due to installation torque or machining variations. It fits into Cavity T-19A with Series 4 capacity handling up to 120 gpm (480 L/min) and operates under pressures up to 5000 psi (350 bar). The control pilot flow ranges between 15-20 in\u00b3/min (0.25-0.33 L/min), with typical response time around 2 ms and maximum leakage at reseat limited to 10 drops/min (0.7 cc/min). Adjustable via an internal hex screw, this model requires specific installation torques and comes with a Viton seal kit option for maintenance needs.
