SUN HYDRAULICS
SCCACWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SCCACWV (SCCACWV) is a direct-acting sequence valve with an integrated reverse flow check, designed to supply a secondary circuit with flow once the inlet port pressure exceeds the valve setting. This model features an integral check valve that allows reverse flow from port 2 to port 1. The valve's pressure setting regulates the pressure at port 1 in relation to the drain port 3. Despite being a zero pilot flow valve, it is crucial that port 3 remains connected to maintain proper pressure reference; blocking this port can lead to malfunction due to seal weepage. The pressure at port 3 directly adds to the valve setting at a ratio of 1:1 and should not surpass 5000 psi (350 bar). This makes it suitable for load-holding applications. All three-port sequence cartridges are interchangeable within their frame size, sharing the same flow path and cavity. Cartridges with EPDM seals are compatible with phosphate ester fluids but are vulnerable to petroleum-based substances, which can damage these seals. Corrosion-resistant variants of this cartridge are available, identified by suffixes AP or LH based on their external component materials. The floating style construction minimizes internal part binding caused by excessive installation torque or machining variations. This model fits into a T-11A cavity and supports a capacity of up to 15 gpm (60 L/min) with maximum operating pressures reaching 5000 psi (350 bar). It has a typical response time of 2 ms and minimal leakage at reseat conditions. The adjustment mechanism allows for precise control over settings, with specific torque requirements for installation and locknut adjustments. Weighing only .30 lb (0.15 kg), this compact unit ensures efficient performance in various hydraulic applications.
