SUN HYDRAULICS
SCCBLWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SCCBLWV (SCCBLWV) is an atmospherically referenced, direct-acting sequence valve equipped with a reverse-flow check. This valve is designed to supply a secondary circuit with flow once the inlet port 1 pressure surpasses the valve setting. It features an integral check valve that allows reverse flow from port 2 to port 1. The pressure setting of this sequence valve regulates the pressure at port 1 relative to the atmospheric vent, making it suitable for load holding applications where a drain connection is not feasible. The design incorporates Sun's floating style construction, which minimizes internal part binding due to excessive installation torque or cavity/cartridge machining variations. The SCCBLWV has a capacity of 15 gpm (60 L/min) and can operate at a maximum pressure of 5000 psi (350 bar). It responds typically within 2 milliseconds and has maximum valve leakage at reseat of 10 drops/min (0.7 cc/min). The check cracking pressure is set at 40 psi (2.8 bar), and the adjustment can be increased by turning clockwise up to five full turns. Installation requires specific torque settings: the valve hex size is 7/8 in. (22.2 mm), with an installation torque between 30 and 35 lbf ft (41 - 47 Nm). The adjustment screw internal hex size is 5/32 in. (4 mm), while the locknut hex size is 9/16 in. (15 mm), requiring a locknut torque of between 80 and 90 lbf in. (9 -10 Nm). The model weighs approximately .30 lb (.15 kg) and uses Viton seal kits available under part number: 990010006.
