SUN HYDRAULICS
SCGACAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SCGACAV (Material Number: SCGACAV) is a direct-acting sequence valve with an integrated reverse flow check, designed to supply a secondary circuit with flow once the pressure at inlet port 1 exceeds the valve setting. This valve features an integral check valve that allows reverse flow from port 2 back to port 1. It controls the pressure at port 1 relative to the drain port 3, and all three-port sequence cartridges are interchangeable, ensuring compatibility across various applications. The valve is suitable for load-holding applications and incorporates Sun's floating style construction, minimizing internal part binding due to installation torque or machining variations. The SCGACAV has a cavity type of T-17A and belongs to Series 3, with a capacity of up to 60 gpm (240 L/min) and a maximum operating pressure of 5000 psi (350 bar). The response time is typically around 2 milliseconds, and it has a maximum valve leakage at reseat of 10 drops/min (0.7 cc/min). The check cracking pressure is set at 25 psi (1.7 bar), and adjustments can be made with five clockwise turns to increase the setting. Installation requires specific torque settings: the valve hex size is 1-1/4 in. (31.8 mm) with an installation torque of 150\u2013160 lbf ft (203\u2013217 Nm), while the adjustment screw internal hex size is 5/32 in. (4 mm), and the locknut hex size is 9/16 in. (15 mm) with torque settings between 80\u201390 lbf in. (9\u201310 Nm). The model weighs approximately 1.50 lb (0.70 kg) and uses Viton seals, available under seal kit number: 990017006.
