SUN HYDRAULICS
SCIALAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SCIALAV (SCIALAV) is a direct-acting sequence valve with an integral reverse-flow check, designed to manage hydraulic flow in secondary circuits once the inlet pressure at port 1 surpasses the pre-set valve threshold. This model incorporates a check valve to facilitate reverse flow from port 2 back to port 1. The pressure setting effectively controls the pressure at port 1 in relation to the drain port 3, and all three-port sequence cartridges can be interchanged physically and functionally for a given frame size. While this valve features zero pilot flow, it is crucial that port 3 remains connected to maintain a proper pressure reference; blocking this port could lead to malfunction due to seal weepage. The pressure at port 3 adds directly to the valve setting on a one-to-one basis and should not exceed 5000 psi (350 bar). The SCIALAV is particularly suitable for load-holding applications and is compatible with systems using phosphate ester fluids when configured with EPDM seals. This configuration prevents damage from petroleum-based fluids or greases. The valve employs Sun's floating style construction, which minimizes internal binding risks due to installation torque or machining variations. It has a capacity of up to 120 gpm (480 L/min) and operates under a maximum pressure of 5000 psi (350 bar), with factory settings calibrated at minimal leakage rates of up to 10 drops per minute upon reseat. Adjustments can be made by turning clockwise, with specific torque specifications for installation and locknut adjustments provided for optimal performance.
