SUN HYDRAULICS
SCIALWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SCIALWV (SCIALWV) is a direct-acting sequence valve with a reverse-flow check, designed to supply a secondary circuit with flow once the inlet port 1 pressure exceeds the valve setting. This valve features an integral check valve that allows reverse flow from port 2 to port 1. The pressure setting controls the pressure at port 1 relative to the drain port 3, and all three-port sequence cartridges are interchangeable in terms of flow path and cavity for a given frame size. Despite being a zero pilot flow valve, it requires port 3 to be connected to maintain control chamber pressure; blocking this can lead to malfunction due to seal weepage. The pressure at port 3 adds directly to the valve setting at a 1:1 ratio, with a maximum limit of 5000 psi (350 bar). This product is suitable for load-holding applications and is constructed using Sun's floating style design to minimize internal binding issues. It supports systems with phosphate ester fluids when configured with EPDM seals but is incompatible with petroleum-based fluids. The cavity type is T-19A, Series 4, with a capacity of up to 120 gpm (480 L/min) and factory pressure settings established at 2 in/min (30 cc/min). It operates at a maximum pressure of 5000 psi (350 bar) and has typical response times of around 2 ms. Maximum leakage upon reseat is limited to 10 drops/min (0.7 cc/min), while check cracking pressure stands at 25 psi (1.7 bar). Adjustments involve five clockwise turns for increased settings, and installation torque ranges between 350-375 lbf ft (474-508 Nm). The model weighs approximately 3.10 lb (1.40 kg), and Viton seal kits are available under part number 990019006.
