SUN HYDRAULICS
SQFBFAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQFBFAN (Material Number: SQFBFAN) is a kickdown sequence valve designed to facilitate an unrestricted flow path from port 1 to port 2 once the inlet pressure at port 1 exceeds the valve setting. This valve remains open as long as the pressure at port 1 surpasses that at port 2, and it resets when the pressure drops below the set threshold, ceasing flow from port 1 to port 2. The valve is particularly suited for applications on the actuator side of hydraulic systems, as it requires cessation of flow for resetting. It features a main stage orifice protected by a 150-micron stainless steel screen and can handle a maximum operating pressure of up to 5000 psi (350 bar). The sequence cartridges are interchangeable across all three ports, maintaining consistent flow paths and cavity compatibility for given frame sizes. However, they are not recommended for load-holding applications due to their operational design. The valve's construction incorporates Sun's floating style to reduce internal binding risks from excessive installation torque or machining variations. It boasts a capacity of 30 gpm (120 L/min) with a typical response time of around 25 ms and minimal leakage rates. Installation details include a hex size of 1-1/8 inches (28.6 mm) with an installation torque range between 45-50 lbf ft (61-68 Nm). Additionally, adjustments can be made through clockwise turns to increase settings, with specific hex sizes provided for adjustment screw and locknut operations. The model weighs approximately .50 lb (0.25 kg), and Viton seal kits are available under part number 990202006 for maintenance or replacement needs.
