SUN HYDRAULICS
SQHBCWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQHBCWV (SQHBCWV) is a versatile kickdown sequence valve designed to provide an unrestricted flow path from port 1 to port 2 once the inlet pressure exceeds the valve setting. This valve is particularly effective in systems where maintaining a consistent flow is crucial, as it remains open as long as the pressure at port 1 surpasses that at port 2. To reset, the pressure must drop below the set level, and flow must cease through ports 1 and 2. This model is not recommended for load-holding applications due to its design. It features a main stage orifice protected by a robust 150-micron stainless steel screen and can handle pressures up to 5000 psi (350 bar), with pressure at port 3 directly adding to the valve setting on a 1:1 ratio. The SQHBCWV is intended for use on the actuator side of hydraulic systems, ensuring that flow cessation allows for proper resetting of the valve; if utilized on the pump side, pump flow must be halted for reset procedures. Its construction incorporates Sun's floating style design, minimizing internal binding risks due to installation or machining variations. The valve fits into cavity T-17A and accommodates a series-3 capacity of up to 60 gpm (240 L/min). Factory pressure settings are established at kickdown points with maximum operating pressures reaching up to 5000 psi (350 bar). It boasts a typical response time of approximately 25 ms and minimal leakage rates under specified conditions. Installation requires precise torque specifications, with adjustments facilitated by an internal hex screw mechanism. The model includes a Viton seal kit option for enhanced durability and weighs approximately 1.50 lb (0.70 kg).
