SUN HYDRAULICS
SQHBKAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQHBKAN (SQHBKAN) is a kickdown sequence valve designed to create an unrestricted flow path from port 1 to port 2 once the pressure at the inlet port 1 exceeds the valve setting. The valve remains open as long as the pressure at port 1 surpasses that at port 2. Resetting occurs when pressure at port 1 falls below the set level, flow ceases, and pressure at port 2 is equal to or greater than at port 1. This valve should not be used in load-holding applications and is intended for use on the actuator side of a system, requiring cessation of flow for resetting. The main stage orifice is protected by a 150-micron stainless steel screen, and pressure at port 3 should not exceed 5000 psi (350 bar). Featuring Sun's floating style construction, it minimizes binding due to excessive installation torque or machining variations. It fits into cavity T-17A, Series 3 with a capacity of up to 60 gpm (240 L/min) and has a factory-set kickdown point with a maximum operating pressure of 5000 psi (350 bar). The typical response time is around 25 ms, with maximum leakage rated at 4 in\u00b3/min (65 cc/min) under specific conditions. Adjustments can be made by turning clockwise up to five turns to increase settings. Installation requires a torque of between 150-160 lbf ft (203-217 Nm), with locknut torque specified between 80-90 lbf in (9-10 Nm). The valve weighs approximately 1.50 lb (0.70 kg), and it comes equipped with Viton seals as standard through cartridge seal kit number: 990017006.
