SUN HYDRAULICS
SQHBKDV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQHBKDV (SQHBKDV) is a kickdown sequence valve designed for hydraulic systems, providing an efficient flow path by kicking completely open and remaining so once the pressure at inlet port 1 exceeds the valve setting. This creates an unrestricted flow from port 1 to port 2, and the valve stays open as long as this pressure condition is maintained. The valve resets when the pressure at port 1 falls below the set threshold, flow ceases, and pressure at port 2 equals or surpasses that at port 1. Notably, this valve should not be used in load-holding applications. It features a main stage orifice protected by a 150-micron stainless steel screen and can handle pressures up to 5000 psi (350 bar). Designed for actuator-side applications, it requires flow cessation for resetting, which must be considered if used on the pump side. The Sun floating style construction minimizes internal part binding due to installation torque or machining variations. The SQHBKDV is interchangeable with other three-port sequence cartridges of similar frame sizes. It has a capacity of 60 gpm (240 L/min) and responds typically within 25 ms. The maximum leakage rate is specified at 4 in\u00b3/min (65 cc/min) with adjustments possible through a screw requiring specific torque settings. Installation requires careful adherence to torque specifications to ensure optimal performance and longevity of the unit.
