SUN HYDRAULICS
SQHBLAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQHBLAV (SQHBLAV) is a kickdown sequence valve designed to provide an unrestricted flow path once the pressure at the inlet port 1 exceeds the valve setting, maintaining an open state as long as the pressure at port 1 surpasses that at port 2. This valve is not suitable for load-holding applications and is intended for use on the actuator side of hydraulic systems. The main stage orifice is safeguarded by a 150-micron stainless steel screen, and pressure at port 3, which influences the valve setting directly at a 1:1 ratio, should not exceed 5000 psi (350 bar). The Sun Hydraulics SQHBLAV features floating style construction to reduce internal binding risks due to installation torque or machining variations. It fits into a T-17A cavity and supports a maximum flow capacity of 60 gpm (240 L/min). The factory pressure settings are established at the kickdown point, with a maximum operating pressure of 5000 psi (350 bar). The typical response time is around 25 ms, and it has minimal leakage rates of up to 4 in\u00b3/min (65 cc/min) at specific conditions. For adjustment, turning clockwise increases settings with five full turns available. Installation requires specific torque values: valve installation torque between 150-160 lbf ft (203-217 Nm), adjustment screw internal hex size of 5/32 in. (4 mm), locknut hex size of 9/16 in. (15 mm), and locknut torque between 80-90 lbf in. (9-10 Nm). Weighing approximately 1.50 lb (0.70 kg), it includes a Viton seal kit option identified as part number 990017006 for maintenance purposes.
