SUN HYDRAULICS
SQHBLCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQHBLCV (SQHBLCV) is a kickdown sequence valve engineered to open completely and maintain an open state once the inlet port 1 pressure surpasses the valve's preset threshold, facilitating an unobstructed flow from port 1 to port 2. This design is tailored for applications where pressure at port 1 needs to exceed the pressure at port 2 for the valve to remain open. To reset, the pressure at port 1 must drop below the set point, with no flow between ports and equal or greater pressure at port 2 compared to port 1. The valve is interchangeable with other three-port sequence cartridges of the same frame size, offering consistent flow paths and cavity dimensions. However, it is not recommended for load-holding tasks. The main stage orifice is safeguarded by a robust 150-micron stainless steel screen. The additive nature of pressure at port 3 enhances the valve setting directly in a 1:1 ratio but should not exceed a maximum of 5000 psi (350 bar). Designed primarily for actuator-side applications, it requires cessation of flow through the valve for resetting; if utilized on the pump side, pump flow must be halted for resetting purposes. The construction incorporates Sun\u2019s floating style to reduce internal binding risks due to installation torque variations or machining discrepancies. Key specifications include a capacity of up to 60 gpm (240 L/min), factory pressure settings established at kickdown point with a maximum operating pressure of 5000 psi (350 bar), and typical response time of approximately 25 ms. The valve ensures minimal leakage with a maximum rate of about 4 in\u00b3/min (65 cc/min) under specific conditions. Installation requires precise torque settings and adjustments are made via an internal hex screw. A Viton seal kit is available as part number 990017006.
