SUN HYDRAULICS
SQHBQAN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQHBQAN (SQHBQAN) is a kickdown sequence valve designed to manage flow in hydraulic systems by completely opening and maintaining an open state once the pressure at inlet port 1 surpasses the pre-set threshold. This creates an unrestricted flow path from port 1 to port 2, with the pressure setting at port 1 being relative to drain port 3. The valve remains open as long as the pressure at port 1 exceeds that of port 2, and it requires a drop in pressure below its setting for resetting. The valve is specifically intended for use on the actuator side of a system, as flow through the valve must cease for it to reset; if used on the pump side, pump flow must be halted for resetting. It features a floating style construction to reduce binding risks due to installation torque or machining variations. This valve incorporates a stainless steel screen protecting its main stage orifice and should not be used in load-holding applications. Its maximum operating pressure is 5000 psi (350 bar), with factory pressure settings established at kickdown points. The response time is typically around 25 ms, and it allows a maximum leakage of 4 in\u00b3/min (65 cc/min) at 110 SUS (24 cSt). The SQHBQAN offers interchangeability with other three-port sequence cartridges of similar frame sizes, maintaining consistent flow paths and cavity dimensions. Adjustments can be made using its internal hex screw, with specific torque requirements provided for installation and locknut adjustments. Additionally, this model's weight is approximately 1.50 lb (0.70 kg), and it comes equipped with Viton seal kits for enhanced durability under various operational conditions.
