SUN HYDRAULICS
SQJBKWN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQJBKWN (SQJBKWN) is a robust kickdown sequence valve designed to facilitate an unrestricted flow path from port 1 to port 2 once the pressure at the inlet port exceeds the valve setting. This mechanism ensures that the valve remains open as long as the inlet pressure surpasses that at port 2, with resetting conditions requiring a drop in pressure below the set point and cessation of flow. The valve is physically and functionally interchangeable with other 3-port sequence cartridges, maintaining a consistent flow path and cavity for a given frame size. It incorporates a floating style construction to reduce internal binding risks due to installation torque or machining variations, making it reliable under various operational conditions. The main stage orifice is safeguarded by a 150-micron stainless steel screen, ensuring durability and longevity. This model should not be used in load-holding applications and is ideally suited for use on the actuator side of hydraulic systems. It features a maximum operating pressure of 5000 psi (350 bar) and can handle capacities up to 120 gpm (480 L/min). The factory pressure settings are established at the kickdown point, with response times typically around 25 ms. The adjustment mechanism allows for fine-tuning with up to five clockwise turns to increase setting, while installation specifics include a torque range of 350 - 375 lbf ft (474 - 508 Nm). Additionally, it includes features such as an internal hex size adjustment screw and locknut torque specifications for secure setup. This model weighs approximately 3.10 lb (1.40 kg) and utilizes Viton seal kits for enhanced performance under various conditions.
