SUN HYDRAULICS
SQJBKWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SQJBKWV (SQJBKWV) is a kickdown sequence valve designed to provide an unrestricted flow path from port 1 to port 2 once the pressure at the inlet port 1 exceeds the valve setting. This valve remains open as long as the pressure at port 1 is greater than that at port 2, and resets only when specific conditions are met: pressure at port 1 must drop below the valve's setting, flow from port 1 to port 2 must stop, and pressure at port 2 must be equal to or greater than that at port 1. It features a main stage orifice protected by a 150-micron stainless steel screen and incorporates Sun's floating style construction to minimize internal part binding due to excessive installation torque or machining variations. The maximum operating pressure is set at 5000 psi (350 bar), with a typical response time of 25 ms and a maximum valve leakage of 5 in\u00b3/min (80 cc/min) at 110 SUS (24 cSt). The SQJBKWV model has a capacity of up to 120 gpm (480 L/min) and should not be used in load-holding applications. It is specifically intended for use on the actuator side of hydraulic systems, as flow through the valve must cease for it to reset. The valve features adjustable settings with five clockwise turns required to increase the setting, and it includes specific installation torque requirements: valve installation torque ranges from 350-375 lbf\u00b7ft (474-508 Nm), while locknut torque ranges from 80-90 lbf\u00b7in (9-10 Nm). This model weighs approximately 3.10 lb (1.40 kg) and comes with an optional Viton seal kit for enhanced durability and performance in various applications.
