SUN HYDRAULICS
SXCACEN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXCACEN (Material Number: SXCACEN) is a direct-acting sequence valve designed to supply a secondary circuit with flow once the inlet port 1 pressure exceeds the valve setting. This model controls the pressure at port 1 relative to the pressure at drain port 3, and all three-port sequence cartridges are interchangeable in terms of flow path and cavity size. Despite being a zero pilot flow valve, it requires that port 3 be connected to maintain a proper pressure reference in the control chamber; otherwise, blocking it could cause malfunction due to reciprocating seal weepage. The pressure at port 3 adds directly to the valve setting at a 1:1 ratio and should not surpass 5000 psi (350 bar). Suitable for load-holding applications, this corrosion-resistant cartridge is ideal for use in corrosive environments, available with stainless steel or zinc-nickel plated components. It features Sun's floating style construction to minimize internal binding risks from excessive installation torque or machining variations. The SXCACEN has a capacity of 15 gpm (60 L/min) with factory pressure settings established at 2 in\u00b3/min (30 cc/min). It operates under a maximum pressure of 5000 psi (350 bar) with typical response times around 2 ms and maximum leakage at reseat of about 10 drops/min (0.7 cc/min). The adjustment can be increased by turning clockwise up to four turns, with installation torque specified between 30 - 35 lbf\u00b7ft (41 - 47 Nm). Seal kits are available for maintenance purposes, including Viton options like part number 990011006.
