SUN HYDRAULICS
SXCAKAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXCAKAV (SXCAKAV) is a direct-acting sequence valve designed to supply a secondary circuit with flow once the pressure at inlet port 1 exceeds the valve setting. This valve is particularly notable for its ability to control pressure at port 1 relative to the pressure at drain port 3, making it suitable for load holding applications. It features a zero pilot flow design, which requires that port 3 be connected to maintain a pressure reference in the control chamber; blocking port 3 can lead to malfunction due to reciprocating seal weepage. The maximum allowable pressure at port 3 is additive to the valve setting at a 1:1 ratio and should not exceed 5000 psi (350 bar). The SXCAKAV model incorporates Sun's floating style construction, minimizing internal parts binding due to excessive installation torque or cavity/cartridge machining variations. It has a cavity size of T-11A, series 1, and offers a capacity of up to 15 gpm (60 L/min). Factory pressure settings are established at 2 in/min (30 cc/min), with a maximum operating pressure of up to 5000 psi (350 bar) and typical response time of around 2 ms. The maximum valve leakage at reseat is minimal, recorded at only 10 drops/min (0.7 cc/min). For adjustments, it requires approximately four clockwise turns to increase settings, and it includes specific hex sizes for both the adjustment screw and locknut. Additionally, the model supports corrosion-resistant options for use in challenging environments and weighs approximately .30 lb (.15 kg).
