SUN HYDRAULICS
SXCAKEN

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXCAKEN (Material Number: SXCAKEN) is a direct-acting sequence valve designed to supply a secondary circuit with flow once the pressure at inlet port 1 surpasses the valve's setting. It controls the pressure at port 1 in relation to the pressure at the drain port 3, with all three-port sequence cartridges being both physically and functionally interchangeable. This zero pilot flow valve requires that port 3 be connected to maintain a pressure reference in the control chamber, as blocking it can lead to valve malfunction due to reciprocating seal weepage. The pressure at port 3 is additive to the valve setting at a 1:1 ratio and should not exceed 5000 psi (350 bar). The SXCAKEN is suitable for load-holding applications and available in corrosion-resistant configurations, identified by model code suffixes AP or LH for external stainless steel or zinc-nickel plated components, respectively. It incorporates Sun's floating style construction, which minimizes internal parts binding due to excessive installation torque or cavity/cartridge machining variations. The SXCAKEN has a cavity size of T-11A, Series 1, with a capacity of 15 gpm (60 L/min) and factory pressure settings established at 2 in\u00b3/min (30 cc/min). It operates under a maximum pressure of 5000 psi (350 bar) with a typical response time of 2 ms. The maximum valve leakage at reseat is limited to ten drops per minute (0.7 cc/min). Adjustment can be made through four clockwise turns to increase settings, with specific torque requirements for installation and adjustment components provided for optimal performance and durability.
