SUN HYDRAULICS
SXCBCCV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXCBCCV (SXCBCCV) is an atmospherically referenced, direct-acting sequence valve designed to supply a secondary circuit with flow once the inlet port 1 pressure exceeds the valve setting. This sequence valve is particularly suitable for load holding applications and should be used where a drain connection is not feasible. It features Sun's floating style construction, which minimizes the risk of internal parts binding due to excessive installation torque or machining variations. The valve has a capacity of 15 gpm (60 L/min) and operates at a maximum pressure of 5000 psi (350 bar). It has a typical response time of 2 ms and allows for maximum valve leakage at reseat of 10 drops/min (0.7 cc/min). The adjustment mechanism allows for up to 44 clockwise turns to increase the setting, and it includes specific hex sizes and torque specifications for installation and adjustment. Additionally, the model weighs .30 lb (0.15 kg) and comes with a Viton seal kit option under cartridge number 990010006. This product is engineered to handle approximately one drop (0.07 cc) of fluid leakage into the vented spring chamber every 4000 cycles, acknowledging potential external leakage or moisture ingress over time due to its atmospheric referencing.
