SUN HYDRAULICS
SXEACDV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXEACDV (SXEACDV) is a direct-acting sequence valve designed to supply a secondary circuit with flow once the pressure at inlet port 1 exceeds the valve's set pressure. This sequence valve is suitable for load-holding applications and features interchangeable 3-port cartridges, maintaining consistent flow paths and cavity compatibility for a given frame size. The valve integrates Sun's floating style construction to minimize internal part binding due to excessive installation torque or cavity machining variations. It operates with a maximum flow capacity of 30 gpm (120 L/min) and withstands operating pressures up to 5000 psi (350 bar). The response time is typically 2 milliseconds, and the maximum valve leakage at reseat is limited to 10 drops per minute (0.7 cc/min). Adjustments can be made with up to four clockwise turns to increase the setting, utilizing an internal hex size of 5/32 inches (4 mm). Installation requires a torque of 45-50 lbf ft (61-68 Nm), while the locknut torque specification is between 80-90 lbf in (9-10 Nm). The valve weighs approximately 0.60 lbs (0.30 kg) and uses Viton seals, with a designated seal kit available as part number 990202006. It\u2019s important that port 3 drain remains unblocked to maintain proper pressure reference in the control chamber; otherwise, reciprocating seal weepage may lead to malfunctioning. Pressure at port 3 should not exceed the additive limit of 5000 psi relative to the valve setting, ensuring reliable performance in hydraulic systems requiring precise pressure control and sequencing functions.
