SUN HYDRAULICS
SXEACWV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXEACWV (SXEACWV) is a direct-acting sequence valve designed to supply a secondary circuit with flow once the pressure at inlet port 1 exceeds the valve setting. This model controls the pressure at port 1 relative to the drain port 3, and all three-port sequence cartridges are interchangeable in terms of flow path and cavity for a given frame size. Despite being a zero pilot flow valve, it requires port 3 to be connected to maintain a pressure reference in the control chamber; blocking port 3 could lead to malfunction due to reciprocating seal weepage. The pressure at port 3 is additive to the valve setting at a 1:1 ratio, which should not exceed 5000 psi (350 bar). It is suitable for load-holding applications and features Sun's floating style construction to minimize internal part binding from excessive installation torque or machining variations. The valve fits into Cavity T-2A, Series 2, with a capacity of up to 30 gpm (120 L/min) and operates under a maximum pressure of 5000 psi (350 bar). Typical response time is around 2 ms, with maximum leakage at reseat being about 10 drops/minute (0.7 cc/min). The adjustment can be increased by turning clockwise up to four turns, with specific hex sizes for various components: valve hex size is 1-1/8 inches (28.6 mm), adjustment screw internal hex size is 5/32 inches (4 mm), and locknut hex size is 9/16 inches (15 mm). Installation torque for the valve ranges from 45-50 lbf ft (61-68 Nm), while locknut torque ranges from 80-90 lbf in (9-10 Nm). The model weighs approximately .60 lb (.30 kg) and uses Viton seal kit number: 990202006.
