SUN HYDRAULICS
SXEAKAV

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Sun Hydraulics directly.***
The Sun Hydraulics SXEAKAV (SXEAKAV) is a direct-acting sequence valve designed to manage the flow to a secondary circuit once the inlet port pressure exceeds the preset valve setting. It features a pressure control mechanism at port 1, which is relative to the pressure at drain port 3, ensuring precise flow management in hydraulic systems. This model is part of a series of interchangeable three-port sequence cartridges, allowing for seamless integration into existing systems with similar flow paths and cavity sizes. The valve requires connection of port 3 to maintain accurate pressure reference in the control chamber; failure to do so may lead to malfunction due to reciprocating seal weepage. The maximum allowable pressure at port 3 is 5000 psi (350 bar), which directly affects the valve setting on a 1:1 ratio basis. The SXEAKAV is suitable for load holding applications and incorporates Sun's floating style construction, minimizing internal part binding from installation torque or machining variations. It boasts a capacity of up to 30 gpm (120 L/min) and operates effectively under pressures up to 5000 psi (350 bar). The typical response time is approximately 2 milliseconds, with maximum valve leakage at reseat limited to 10 drops/minute (0.7 cc/min). Adjustments can be made via an internal hex screw, with four clockwise turns increasing the setting. Installation requires specific torque settings: valve hex size of 1-1/8 inches (28.6 mm) with torque between 45-50 lbf-ft (61-68 Nm), and locknut torque between 80-90 lbf-in (9-10 Nm). The model weighs approximately .60 lb (.30 kg) and utilizes Viton seals for durability and reliability in various hydraulic applications.
